4-INCH DIAMETER

CEMA B
20
BELTEFHRL
18″27″10.25″8.25″6.75″
24″33″11″8.25″8.75″
30″39″11.625″8.25″10.75″
36″45″12.375″8.25″12.75″
PART #WEIGHT
18-242-HSTE-U61 LBS.
24-242-HSTE-U68 LBS.
30-242-HSTE-U84 LBS.
36-242-HSTE-U94 LBS.

4-INCH DIAMETER

CEMA B
35

BELTEFHRL
18"27"12"8.25"6.75"
24"33"13.25"8.25"8.75"
30"39"14.375"8.25"10.75"
36"45"15.5"8.25"12.75"
PART #WEIGHT
18-342-HSTE-U64 LBS.
24-342-HSTE-U71 LBS.
30-342-HSTE-U88 LBS.
36-342-HSTE-U98 LBS.

5-INCH DIAMETER

CEMA B
20

BELTEFHRL
18"27"10.75"8.75"6.75"
24"33"11.5"8.75"8.75"
30"39"12.125"8.75"10.75"
36"45"12.875"8.75"12.75"
42"51"13.5"8.75"14.75"
48"57"14.25"8.75"16.75"
PART #WEIGHT
18-252-HSTE-U65 LBS.
24-252-HSTE-U73 LBS.
30-252-HSTE-U90 LBS.
36-252-HSTE-U100 LBS.
42-252-HSTE-U114 LBS.
48-252-HSTE-U121 LBS.

5-INCH DIAMETER

CEMA B
35

BELTEFHRL
18"27"12.5"8.75"6.75"
24"33"13.5"8.75"8.75"
30"39"14.75"8.75"10.75"
36"45"15.875"8.75"12.75"
42"51"17"8.75"14.75"
48"57"18.125"8.75"16.75"
PART #WEIGHT
18-352-HSTE-U68 LBS.
24-352-HSTE-U76 LBS.
30-352-HSTE-U94 LBS.
36-352-HSTE-U104 LBS.
42-352-HSTE-U115 LBS.
48-352-HSTE-U123 LBS.
